1.5KW Single Phase Off Grid Inverter Rs485 Compatible With Lifepo4 Battery Inverter
1.5KW Single Phase Off Grid Inverter Rs485 Compatible With Lifepo4 Battery Inverter
  • 1.5KW Single Phase Off Grid Inverter Rs485 Compatible With Lifepo4 Battery Inverter
  • 1.5KW Single Phase Off Grid Inverter Rs485 Compatible With Lifepo4 Battery Inverter
  • 1.5KW Single Phase Off Grid Inverter Rs485 Compatible With Lifepo4 Battery Inverter

1.5KW Single Phase Off Grid Inverter Rs485 Compatible With Lifepo4 Battery Inverter

Product Details:
Place of Origin: China
Brand Name: RESUN
Certification: -
Model Number: O-1.5K-LSM
Detail Information
Place of Origin:
China
Brand Name:
RESUN
Certification:
-
Model Number:
O-1.5K-LSM
Model:
O-1.5K-LSM
Power Rating:
1.5KW
Max Efficiency:
96%
Operating Temperature Range:
-10 To 50°C
Battery Compatibility:
Lead-acid / Li-ion / User-defined
Rated Battery Voltage:
24V
Cooling Method:
Heatsink & Intelligent Air Cooling
Input Voltage Range:
50/60Hz
PV INPUT DC Voltage, Current:
60~500Vdc，15A
Communication Interface:
RS232+RS485
Warranty:
18 Months
Highlight:

High Light

Highlight:

1.5KW Single Phase Off Grid Inverter

,

Single Phase Off Grid Inverter Rs485

,

Lifepo4 Battery Off Grid Inverter

Trading Information
Minimum Order Quantity:
1pcs
Price:
Negotiable
Delivery Time:
3-30days
Payment Terms:
T/T
Supply Ability:
10000
Product Description


1.5KW Off grid Rs485 compatible with Lifepo4 battery inverter

•   Specially designed for off grid scenarios, supporting RS485 communication protocol, seamlessly compatible with LiFePO4 batteries, achieving data exchange and collaborative management between inverters and battery systems. ​
•   No need to rely on the power grid, operate independently to drive various loads; PV input voltage range of 60-500Vdc, efficient conversion of solar energy. ​
•   Built in MPPT technology improves power generation efficiency, optimizes battery charging and discharging logic, and extends the service life of energy storage systems.


 Product Features
•   Lithium battery activation function by PV or UtilityCompatible work with lifepo4 battery via Rs485
•   Pure sine wave
•   Powerfactor1.0
•   PVinput Voltage 60Vdc-500VdcBuilt-inMPPT60A/100A/120A

Description

  MODEL O-1.5K-LSM
  Capacity 1.5KVA/1.5KW
  Parallel Capability NO
  Lithium Battery activation YES(By PV only)
  Lithium Battery communication YES(RS485)
  INPUT
  Nominal Voltage 230VAC
  Acceptable Votage Range 170-280VAC(For personal Computer);90-280vac(For Home Appliances)
  Frequency 50/60 Hz(Auto sensing)
  OUTPUT
  Nominal Voltage 220/230VAC±5%
  Surge Power 3000VA
  Frequency 50/60Hz
  Waveform Pure Sine wave
  Transfer Time 10ms(For personal Computer);20ms(For Home Appliances)
  Peak Efficiency(PV to INV) 96%
  Peak Efficiency(Battery to INV) 93%
  Overload Protection 5s@>=140%load;10s@110%~140%load
  Crest Factor 3:1
  Admissible Power Factor 0.6~1(inductive or capacitive)
  BATTERY
  Battery Voltage 24VDC
  Floating Charge Voltage 27VDC
  OverCharge Protection 33VDC
  Charging Method CC/CV
  Lithium Battery Activation YES(By PV
  Lithim battery Communication YES(RS485)
  SOLAR  CHARGER  &AC  CHARGER
  Solar Charger Type MPPT
  Max.PV Array Power 2000W
  Max.PV Array Open Circuit Voltage 500VDC
  PV Array MPPT Voltage Range 60VDC~500VDC
  Max.Solar Input Current 15A
  Max.Solar Charge Current 60A
  Max.AC Charge Current 60A
  Max.Charge Current(PV+AC) 60A
  PHYSICAL
  Dimensions,DxWxH(mm) 358*295*100
  Package Dimensions,D×WxH(mm) 465*380*175
  Net Weight(Kg) 6
  Communication Interface RS232+RS485
  ENVIRONMENT
  Operating Temperature Range (-10℃ to 50℃)
  Storage Temperature (-15℃~50℃)
  Humidity 5%to 95%Relative Humidity(Non-condensing)
