2.5KW Off Grid Pure Sine Wave Inverter RS232 RS485 2.5KVA

Name: 2.5KW Off Grid Pure Sine Wave Inverter RS232 RS485 2.5KVA
Brand: Shenzhen Resun energy Technology Co., Ltd
SKU: O-2.5K-LSM
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	RESUN
Certification:	-
Model Number:	O-2.5K-LSM

Detail Information

Place of Origin:

China

Brand Name:

RESUN

Certification:

Model Number:

O-2.5K-LSM

Model:

O-2.5K-LSM

Power Rating:

2.5KW

Max Efficiency:

96%

Operating Temperature Range:

-10 To 50°C

Battery Compatibility:

Lead-acid / Li-ion / User-defined

Rated Battery Voltage:

24V

Cooling Method:

Heatsink & Intelligent Air Cooling

Input Voltage Range:

50/60Hz

PV INPUT DC Voltage, Current:

60~500Vdc，15A

Communication Interface:

RS232+RS485

Warranty:

18 Months

Highlight:

High Light

Highlight:

Off Grid Sine Wave Inverter

2.5KW Pure Sine Wave Inverter

Off Grid Inverter 2.5KVA

Trading Information

Minimum Order Quantity:

1pcs

Price:

Negotiable

Delivery Time:

3-30days

Payment Terms:

T/T

Supply Ability:

10000

Product Description

2.5KW Pure sine wave off grid inverter

• Using pure sine wave technology, the output current waveform is consistent with the mains power, without harmonic interference, and reduces equipment losses.
• Specially designed for off grid scenarios, suitable for remote mountainous areas, wilderness camps, emergency rescue and other scenarios, providing users with continuous and stable electricity.
• Automatically adjust output power to adapt to complex electrical environments and ensure long-term reliable operation.

Product Features
• Lithium battery activation function by PV or UtilityCompatible work with lifepo4 battery via Rs485
• Powerfactor1.0
• PVinput Voltage 60Vdc-500VdcBuilt-inMPPT60A/100A/120A
• Capable to work without battery

Description

MODEL				O-2.5K-LSM
Capacity				2.5KVA/2.5KW
Parallel Capability				NO
Lithium Battery activation				YES(By PV only)
Lithium Battery communication				YES(RS485)
INPUT
Nominal Voltage				230VAC
Acceptable Votage Range				170-280VAC(For personal Computer);90-280vac(For Home Appliances)
Frequency				50/60 Hz(Auto sensing)
OUTPUT
Nominal Voltage				220/230VAC±5%
Surge Power				5000VA
Frequency				50/60Hz
Waveform				Pure Sine wave
Transfer Time				10ms(For personal Computer);20ms(For Home Appliances)
Peak Efficiency(PV to INV)				96%
Peak Efficiency(Battery to INV)				93%
Overload Protection				5s@>=140%load;10s@110%~140%load
Crest Factor				3:1
Admissible Power Factor				0.6~1(inductive or capacitive)
BATTERY
Battery Voltage				24VDC
Floating Charge Voltage				27VDC
OverCharge Protection				33VDC
Charging Method				CC/CV
Lithium Battery Activation				YES(By PV
Lithim battery Communication				YES(RS485)
SOLAR CHARGER &AC CHARGER
Solar Charger Type				MPPT
Max.PV Array Power				3000W
Max.PV Array Open Circuit Voltage				500VDC
PV Array MPPT Voltage Range				60VDC~500VDC
Max.Solar Input Current				15A
Max.Solar Charge Current				100A
Max.AC Charge Current				60A
Max.Charge Current(PV+AC)				100A
PHYSICAL
Dimensions,DxWxH(mm)				*358295100*
Package Dimensions,D×WxH(mm)				*465380175*
Net Weight(Kg)				6.5
Communication Interface				RS232+RS485
ENVIRONMENT
Operating Temperature Range				(-10℃ to 50℃)
Storage Temperature				(-15℃~50℃)
Humidity				5%to 95%Relative Humidity(Non-condensing)
