6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface
6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface
  • 6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface
  • 6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface
  • 6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface
  • 6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface

6.2KW Single Phase Off Grid Inverter with RS485 Communication Interface

Product Details:
Place of Origin: China
Brand Name: RESUN
Model Number: O-6.2K-LSM
Detail Information
Place of Origin:
China
Brand Name:
RESUN
Model Number:
O-6.2K-LSM
Model:
O-6.2K-LSM
Power Rating:
6.2KW
Max Efficiency:
96%
Operating Temperature Range:
-10 To 50°C
Battery Compatibility:
Lead-acid / Li-ion / User-defined
Rated Battery Voltage:
48V
Cooling Method:
Heatsink & Intelligent Air Cooling
Input Voltage Range:
50/60Hz
PV INPUT DC Voltage, Current:
60~500Vdc，27A
Communication Interface:
RS232+RS485
Warranty:
18 Months
Highlight:

High Light

Highlight:

6.2KW Single Phase Off Grid Inverter

,

RS485 Single Phase Off Grid Inverter

,

6.2KW Off Grid Inverter

Trading Information
Minimum Order Quantity:
1pcs
Price:
Negotiable
Delivery Time:
3-30days
Payment Terms:
T/T
Supply Ability:
10000
Product Description


6.2KW Off grid high-efficiency inverter

•   Specially designed for areas without grid coverage, supporting the integration of multiple energy sources such as photovoltaics and energy storage batteries. In mountainous villages, outdoor base stations, RV camping and other scenarios, a stable power system can be quickly established. ​
•   Equipped with advanced MPPT technology, the highest conversion efficiency reaches 99%, reducing energy loss, fully utilizing clean energy, and reducing energy waste. ​
•   Built in intelligent chip, automatically adjusts output power, adapts to different load requirements; Support remote monitoring and management, optimize system performance in real-time, and ensure long-term efficient operation.



 Product Features
•   Powerfactor1.0
•   PVinput Voltage 60Vdc-500VdcBuilt-inMPPT60A/100A/120A
•   Capable to work without battery

•   EQ function to optimize battery performance and extend lifecycle


Description

  MODEL O-6.2K-LSM
  Capacity 6.2KVA/6.2KW
  Parallel Capability NO
  Lithium Battery activation YES ( By PV or Utility)
  Lithium Battery communication YES(RS485)
  INPUT
  Nominal Voltage 230VAC
  Acceptable Votage Range 170-280VAC(For personal Computer);90-280vac(For Home Appliances)
  Frequency 50/60 Hz(Auto sensing)
  OUTPUT
  Nominal Voltage 220/230VAC±5%
  Surge Power 12400VA
  Frequency 50/60Hz
  Waveform Pure Sine wave
  Transfer Time 10ms(For personal Computer);20ms(For Home Appliances)
  Peak Efficiency(PV to INV) 96%
  Peak Efficiency(Battery to INV) 93%
  Overload Protection 5s@>=140%load;10s@110%~140%load
  Crest Factor 3:1
  Admissible Power Factor 0.6~1(inductive or capacitive)
  BATTERY
  Battery Voltage 48VDC
  Floating Charge Voltage 54VDC
  OverCharge Protection 63VDC
  Charging Method CC/CV
  Lithium Battery Activation YES(By PV
  Lithim battery Communication YES(RS485)
  SOLAR  CHARGER  &AC  CHARGER
  Solar Charger Type MPPT
  Max.PV Array Power 6500W
  Max.PV Array Open Circuit Voltage 500VDC
  PV Array MPPT Voltage Range 60VDC~500VDC
  Max.Solar Input Current 27A
  Max.Solar Charge Current 120A
  Max.AC Charge Current 80A
  Max.Charge Current(PV+AC) 120A
  PHYSICAL
  Dimensions,DxWxH(mm) 438*295*105
  Package Dimensions,D×WxH(mm) 560*375*185
  Net Weight(Kg) 9
  Communication Interface RS232+RS485
  ENVIRONMENT
  Operating Temperature Range (-10℃ to 50℃)
  Storage Temperature (-15℃~50℃)
  Humidity 5%to 95%Relative Humidity(Non-condensing)
