Home > Products >
Single Phase Off Grid Inverter
>
1.5KW Single Phase Off Grid Inverter
  • 1.5KW Single Phase Off Grid Inverter
  • 1.5KW Single Phase Off Grid Inverter
  • 1.5KW Single Phase Off Grid Inverter
  • 1.5KW Single Phase Off Grid Inverter

1.5KW Single Phase Off Grid Inverter

Product Details:
Place of Origin: China
Brand Name: RESUN
Certification: -
Model Number: O-1.5K-LSM
Detail Information
Place of Origin:
China
Brand Name:
RESUN
Certification:
-
Model Number:
O-1.5K-LSM
Model:
O-1.5K-LSM
Power Rating:
1.5KW
Max Efficiency:
96%
Operating Temperature Range:
-10 To 50°C
Battery Compatibility:
Lead-acid / Li-ion / User-defined
Rated Battery Voltage:
24V
Cooling Method:
Heatsink & Intelligent Air Cooling
Input Voltage Range:
50/60Hz
PV INPUT DC Voltage, Current:
60~500Vdc，15A
Communication Interface:
RS232+RS485
Warranty:
18 Months
Highlight:

High Light

Highlight:

1.5KW Single Phase Off Grid Inverter

,

Single Phase Off Grid Inverter Rs485

,

Lifepo4 Battery Off Grid Inverter

Trading Information
Minimum Order Quantity:
1pcs
Price:
Negotiable
Delivery Time:
3-30days
Payment Terms:
T/T
Supply Ability:
10000
Product Description
1.5KW Single Phase Off Grid Inverter
Product Overview

This 1.5KW off-grid inverter is specifically engineered for standalone power systems, featuring RS485 communication protocol for seamless compatibility with LiFePO4 batteries. It enables efficient data exchange and collaborative management between inverters and battery systems.

  • Operates independently without grid dependency to power various loads
  • PV input voltage range of 60-500V DC for efficient solar energy conversion
  • Built-in MPPT technology enhances power generation efficiency
  • Optimized battery charging and discharging logic extends energy storage system lifespan
Key Features
  • Lithium battery activation function via PV or utility power
  • Compatible with LiFePO4 batteries via RS485 communication
  • Pure sine wave output for clean power delivery
  • Power factor of 1.0 for optimal efficiency
  • PV input voltage range: 60V DC - 500V DC with built-in MPPT (60A/100A/120A)
Technical Specifications
MODEL O-1.5K-LSM
Capacity 1.5KVA / 1.5KW
Parallel Capability No
Lithium Battery Activation Yes (By PV only)
Lithium Battery Communication Yes (RS485)
Input Specifications
Nominal Voltage 230V AC
Acceptable Voltage Range 170-280V AC (Personal Computer)
90-280V AC (Home Appliances)
Frequency 50/60 Hz (Auto sensing)
Output Specifications
Nominal Voltage 220/230V AC ±5%
Surge Power 3000VA
Frequency 50/60Hz
Waveform Pure Sine Wave
Transfer Time 10ms (Personal Computer)
20ms (Home Appliances)
Peak Efficiency (PV to INV) 96%
Peak Efficiency (Battery to INV) 93%
Overload Protection 5s @ ≥140% load
10s @ 110%-140% load
Crest Factor 3:1
Admissible Power Factor 0.6-1.0 (inductive or capacitive)
Battery Specifications
Battery Voltage 24V DC
Floating Charge Voltage 27V DC
OverCharge Protection 33V DC
Charging Method CC/CV
Lithium Battery Activation Yes (By PV)
Lithium Battery Communication Yes (RS485)
Solar & AC Charger Specifications
Solar Charger Type MPPT
Max. PV Array Power 2000W
Max. PV Array Open Circuit Voltage 500V DC
PV Array MPPT Voltage Range 60V DC - 500V DC
Max. Solar Input Current 15A
Max. Solar Charge Current 60A
Max. AC Charge Current 60A
Max. Charge Current (PV+AC) 60A
Physical Specifications
Dimensions, D*W*H (mm) 358 * 295 * 100
Package Dimensions, D*W*H (mm) 465 * 380 * 175
Net Weight 6 kg
Communication Interface RS232 + RS485
Environmental Specifications
Operating Temperature Range -10℃ to 50℃
Storage Temperature -15℃ to 50℃
Humidity 5% to 95% Relative Humidity (Non-condensing)
